UH407 1.0
Interfaces Upstream Connection 1× USB-C 3.2 Gen 1 Male Connector (5 Gbps)
Video Output 1× HDMI 2.0
Video Output Resolutions
4K (4096×2160) 60 Hz
2K (2560×1440) 144 Hz
1080P (1920×1080) 240 Hz
Video Output Modes Extend, Mirror
Android phone supports mirror mode only
USB Ports
1× USB-C 3.2 Gen 1 Port (5 Gbps)
2× USB-A 3.2 Gen 1 Ports (5 Gbps)
Memory Card Slots
1× SD Card Slot (31.25 MB/S)
1× TF Card Slot (31.25 MB/S)
Power Interfaces USB-C Port
LED Power
Power Power Methods DC / PD
Power Input-an-unordered-list 5-20V?0-5A
Max Power Consumption (W) 100W if powered by a PD Adapter
15W if powered by the host client's USB Power
Idle Power Consumption (W) 0.4W
Physical Color Silver Gray Color
Casing
Aluminum
ABS
Requirements Hardware Requirement Requires a USB-C 3.2 Gen 1 / USB4 / Thunderbolt 3/4 port on the host device
Compatible OS
Windows 7 or later
macOS 10.12 or later
Ubuntu LTS 18.04 or later
Android 5 or higher
iPadOS
iOS
Nintendo Switch system software (When the PD-IN port is receiving power)
Driver Installation Driver Free
Reliability Environment
Operating Temperature: 0~40 °C (-32~104 °F)
Storage Temperature: -20~70 °C (-10~158 °F)
Operating Humidity: 20~85% RH non-condensing
Storage Humidity: 10~90% RH non-condensing
Mechanical Product Weight 62.6 g (2.21 oz.)
Dimension Main Part :
130×32×11 mm
5.12×1.26×0.43 inches
Cable:
250 mm
9.84 inches
Package Content
UH407
Installation Guide
Ordering Information Retail Package Weight 115.2 g (4.06 oz.)
Retail Package Dimension 90×225×18 mm
3.54×8.86×0.71 inches
Units per Carton 100
Carton Net Weight 11.5 kg (25.35 lbs)
Carton Gross Weight 12.5 kg (27.56 lbs)
Carton Dimension 52×46.5×21 cm
20.47×18.31×8.27 inches
