P/N
LTP-0550P-2
WATTS
550W
VENTILADOR RGB
No
FACTOR DE FORMA
ATX
MODELO
LTP-550AL2NK
TIPO
ATX 12V 2.3
MAX. OUTPUT CAPACITY
550W
COLOR
Black
DIMENSION ( W / H / D )
150mm x 86mm x 140mm
PFC (POWER FACTOR CORRECTION)
Active PFC
POWER GOOD SIGNAL
100-500 msec.
HOLD UP TIME
>16msec
INPUT CURRENT
7A
INPUT FREQUENCY RANGE
50Hz - 60Hz
INPUT VOLTAGE
230V
OPERATING TEMPERATURE
+5? to +35?
OPERATING HUMIDITY
20% to 85%,non-condensing
STORAGE TEMPERATURE
-40? to +55?
STORAGE HUMIDITY
10% to 95%, non-condensing
COOLING SYSTEM
120mm Fan: 1800±10% RPM
MTBF
100,000 hrs minimum
SAFETY APPROVAL
CE, TUV SUD, CB, EAC and RCM certified.
PCI-E 6+2PIN
6+2pin PCI-E Connector x 2
