Part No 9S6-3PE0CM-012
Color ID1/Black-Black
Screen Size 21.45" (54.48 cm)
Active Display Area (mm) 478.656 (H) x 260.28 (V)
Curvature Flat
Panel Type VA
Resolution 1920x1080 (FHD)
Pixel pitch (mm) 0.2493(H)x0.241(V)
Aspect Ratio 16:9
Dynamic Refresh Rate technology Adaptive-Sync
Dynamic Refresh Rate Activated Range 48~100Hz
SDR Brightness (nits) 300
Contrast Ratio 4000:1
DCR (Dynamic Contrast Ratio) 100000000:1
Signal Frequency 52.1~110 KHz(H) / 48~100 Hz(V)
Refresh Rate 100HZ
Response Time (MPRT) 1ms(MPRT)
Response Time (GTG) 4ms
View Angles 178°(H)/178°(V)
NTSC (CIE1976 area percentage/overlap) 86.5%/80.71%
NTSC (CIE1931 area percentage/overlap) 74.4%/72.47%
sRGB (CIE1976 area percentage/overlap) 100%/94.11%
sRGB (CIE1931 area percentage/overlap) 105%/96.11%
Adobe RGB (CIE1976 area percentage/overlap) 85.51%/82.6%
Adobe RGB (CIE1931 area percentage/overlap) 77%/74.89%
DCI-P3 (CIE1976 area percentage/overlap) 77.13%/77.15%
DCI-P3 (CIE1931 area percentage/overlap) 76.52%/76.51%
Rec.709 (CIE1976 area percentage/overlap) 100%/94.11%
Rec.709 (CIE1931 area percentage/overlap) 105%/96.11%
Rec.2020 (CIE1976 area percentage/overlap) 57.25%/57.25%
Rec.2020 (CIE1931 area percentage/overlap) 55.05%/55.05%
Surface Treatment Anti-glare
Display Colors 1.07B
Color bit 10 bits (8 bits + FRC)
D-Sub 1
Lock type Kensington Lock
HDMI 1
HDMI version 1.4b
HDMI HDCP version 1.4
Warranty 36M
Power Type Internal Power Board
Power Input 100~240V, 50/60Hz
On-mode Power Consumption (KWh/1000h) 15
Annual Energy Consumption (KWh) 22
Standby-mode Power Consumption (W) 0.5
Off-mode Power Consumption (W) 0.3
Energy Efficiency Rating E
Power Cord Type C13
DisplayPort Cable 0
HDMI Cable 1
DVI Cable 0
USB Type A to Type B Cable 0
USB Type C to Type A Cable 0
USB Type C to Type C Cable 0
Thunderbolt Cable 0
VGA Cable 0
3.5mm audio Cable 0
3.5mm combo audio Cable 0
3.5mm Mic Cable 0
Power Cord 1
AC Adaptor 0
Quick Guide 1
Warranty Card 0
Mouse Bungee Unit 0
Adjustment (Tilt) -5° ~ 20°
VESA Mounting 100x100mm
Product Dimension with Stand (WxDxH) (mm) 492.2 x 182.4 x 377.8
Product Dimension without Stand (WxDxH) (mm) 492.2 x 51.6 x 283.1
Stand Dimension (WxDxH) (mm) 200.4 x 182.4 x 143.8
Weight (Net kg) 2.5
Weight Without Stand (kg) 2.2
Inside Carton Dimension (WxDxH) (cm) 55.7 x 10.8 x 34
Outer Carton Dimension (WxDxH) (cm) 56.7 x 11.8 x 36.5
Weight (Gross kg) 4.3
EAN 4711377261142
