Processor Intel® Core™ i7-1355U, 10C (2P + 8E) / 12T, P-core 1.7 / 5.0GHz, E-core 1.2 / 3.7GHz, 12MB
Graphics Integrated Intel® Iris® Xe Graphics
ChipsetIntel® SoC Platform
Memory8GB Soldered DDR4-3200 + 8GB SO-DIMM DDR4-3200
Memory Slots One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Max Memory Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200
Storage512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
Storage Slots Two M.2 slots
• One M.2 2242 PCIe® 3.0 x4 slot
• One M.2 2242 PCIe 4.0 x4 slot
Card Reader No card reader
OpticalNone
Audio Chip High Definition (HD) Audio, Synaptic® CX11880 codec
Speakers Stereo speakers, 2W x2, Dolby® Atmos®
CameraHD 720p with Privacy Shutter
Microphone 2x, Array
BatteryIntegrated 47Wh
Power Adapter65W USB-C® (2-pin)
DESIGN
Display14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC
Touchscreen None
Keyboard Non-backlit, Spanish (LA)
Case Color Graphite Black
Case MaterialAluminium (Top), PC-ABS (Bottom)
Dimensions (WxDxH) Starting at 313 x 219.3 x 17.99 mm (12.32 x 8.63 x 0.71 inches)
WeightStarting at 1.41 kg (3.11 lbs)
SOFTWARE
Operating System Windows® 11 Pro, Spanish
Bundled Software None
CONNECTIVITY
Ethernet 100/1000M (RJ-45)
WLAN + Bluetooth Wi-Fi® 6, 11ax 2x2 + BT5.1
WWAN None
SIM Card None
NFC None
Standard Ports
1x USB 2.0
1x USB 3.2 Gen 1 (Always On)
1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
Docking
Various docking solutions supported via Thunderbolt™ or USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® E14 Gen 5 (Intel®)
