Versión del modelo AP3000 1.0
CPU CPU Details 1.3 GHz Dual-Core CPU
Memory/Storage Flash/ROM 256 MB (2 Gbit) NAND
DDR/RAM 512 MB (4 Gbit) DDR4
Wireless 5 GHz Wi-Fi Speed 2402Mbps
2.4 GHz Wi-Fi Speed 574 Mbps
5 GHz Wi-Fi Streams 2 Spatial Streams with 3T3R
2.4 GHz Wi-Fi Streams 2 Spatial Streams
Wi-Fi Antennas 5× Internal
FEM or PA/LNA 5 GHz: 3× External, 2.4 GHz: 2× External
Beamforming True
Range Performance Max: 200 m (656 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
Wall Performance Two wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
Interfaces 2.5G RJ45 Ports 1
Ethernet Notes ETH0: PoE In
Buttons and LEDs LED System
Physical Buttons Reset Button
Power Power Input Type
DC Jack
PoE via Ethernet Port
Power Methods
DC
802.3at/af PoE
Passive PoE
Power Input
DC: 12V?1.5A
Passive PoE: 48-57V?
PoE: 802.3at/af
Max Power Consumption (W) 12W (48V PoE), 12W (DC)
Idle Power Consumption (W) 6.1W (48V PoE), 6.1W (DC)
Power Adapter In the Box AP3000 | No adapter in the box
AP3000_P | PoE adapter in the box:
Input: 100 ~ 240 V, 50/60 Hz AC
Output: 48V Passive PoE
Reliability Advanced Hardware Watchdog
EMC ESD: Contact: 4kV; Air: 8kV
Environment Operating Temperature: -10 ? ~ 60 ? (14 ? ~140 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Certifications FCC, CE
Mechanical Installation
Wall-mount
Ceiling-mount
Dimension F231.9×57.1 mm
F9.13×2.25 inches
Product Weight
With PoE Adapter (_P) | EU: 489.6 g (17.27 oz.)
EU: 489.6 g (17.27 oz.)
Package Content
AP3000
Mounting Kit
Installation Guide
PoE Adapter (_P Model Only)
Ethernet Cable (_P Model Only)
Ordering Information Retail Package Weight
With PoE Adapter (_P) | EU: 1015 g (35.8 oz.)
EU: 850.9 g (30.01 oz.)
Retail Package Dimension 283×238×68 mm
11.14×9.37×2.68 inches
Units per Carton 20
Carton Net Weight
With PoE Adapter (_P) | EU: 20.3 kg (44.75 lbs)
EU: 17.0 kg (37.48 lbs)
UK: 19 kg (41.89 lbs)
Carton Gross Weight
With PoE Adapter (_P) | EU: 21.7 kg (47.84 lbs)
EU: 18.2 kg (40.12 lbs)
UK: 20.2 kg (44.53 lbs)
Carton Dimension 58×37.5×49.5 cm
22.83×14.76×19.49 inches
Compatibility Compatible Products C200P 1.0, C500P 1.0
Compatible Accessories POE200H 1.0, POE52-30W 1.0, POE48-18W 1.0
Note Choose with caution: some suggested models may not deliver speeds that match the device’s maximum capability.
