CARACTERÍSTICAS DE HARDWARE
Interface 1× 2.5G Ethernet Port
Botón Reset
Fuente de alimentación 802.3at PoE or 12V/1.5A DC (Power Adapter Is Not Included)
Consumo de Poder • 18.6 W (For PoE);
• 16.0 W (For DC)
Dimensiones (An x Pr x Al) 6.3 × 6.3 × 1.4 in (160 × 160 × 36.7 mm)
Tipo de Antena • 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
Montaje Ceiling / Wall Mounting (Kits Included)
CARACTERÍSTICAS INALÁMBRICAS
Coverage 140?(1500 ft²)***
Wireless Client Capacity 250+**
Estándares inalámbricos IEEE 802.11 a/b/g/n/ac/ax/be
Frecuencia 2.4 GHz and 5 GHz
Tasa de señal 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz)
Funciones inalámbricas • 4K-QAM‡
• Seamless Roaming
• MU-MIMO‡
• EHT160‡
• Mesh?
• OFDMA‡
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS:16(8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication
Seguridad inalámbrica • Captive Portal Authentication?
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Poder de transmision < 20 dBm (2.4 GHz, EIRP)
< 23 dBm (5 GHz, band 1&band 2, EIRP)
< 28 dBm (5 GHz, band 3, EIRP)
ADMINISTRACIÓN
Aplicación Omada Yes
Gestión centralizada • Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Acceso a la nube Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.
Alertas de correo electrónico Yes
Control de LED ENCENDIDO / APAGADO Yes
Gestión de control de acceso MAC Yes
SNMP v1, v2c, v3
Registro del sistema Local / Remote Syslog Yes
Gestión basada en web Yes
OTROS
Certificación CE, FCC, RoHS, IC
contenidos del paquete • EAP723
• Installation Guide
• Ceiling/Wall Mounting Kit
Ambiente • Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing;
