Interfaces Gigabit RJ45 Ports 8
LED
Power
Link/ACT of Each Ethernet Port
Power Interfaces DC Jack
Performance Max Copper Speed and Distance
Cat. 3 or higher cable: 100 meters at 10 Mbps
Cat. 5 or higher cable: 100 meters at 100 Mbps
Cat. 5e or higher cable: 170 meters at Gigabit
MAC Address Table 4096
Max Switching Capacity 16 Gbps
Max Forwarding Rate 11.904 Mpps
Jumbo Frame 15 KB
Packet Buffer 1.5 Mbit
Power Basic Power Saving
Power Methods DC
Power Input 5V?0.55A
Power Adapter in the Box Input: 100-240V~, 50/60Hz
Output: 5V?0.55A
Max Power Consumption 1.8W
Idle Power Consumption 0.3W
Switching 802.3 Protocols
802.3x Flow Control
802.3i 10BASE-T
802.3u 100BASE-TX
802.3ab 1000BASE-T
L2 Features
IGMP Snooping
Loop Prevention
Loop Detection
Reliability EMS IEC/EN 61000-4-2, Level 2 ESD: Contact: 4kV; Air: 8kV
IEC/EN 61000-4-5, Level 3 Surge: 2kV
Environment Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Mechanical Dimension 138×78×25 mm
5.43×3.07×0.98 inches
Product Weight 205.9 g (7.26 oz.)
Casing Material Metal
Installation
Desktop
Wall-mount
Package Content
GS108
Power Adapter
Installation Guide
